| Display |
Screen size
9" IPS
Resolution
800x480
Brightness
>1200 nits
|
Touchscreen
Multitouch
Keypad
Pages, waypoint, zoom, power, (1) user programmable quick access keys
Viewing angles in degrees
50° top 60° bottom 70° left/right
|
| Sonar |
Sonar compatibility
Integrated:
CHIRP, Broadband, Active Imaging™ HD DownScan*, Active Imaging™ HD SideScan*, Active Imaging™ DownScan, Active Imaging™ SideScan
*requires S3100 module
Compatible with:
ActiveTarget® 2, ActiveTarget®, S3100, SonarHub®, StructureScan®, StructureScan®HD, StructureScan®3D, LiveSight (requires PSI-1 module)
|
Sonar frequencies
CHIRP
High CHIRP
Medium CHIRP
Low CHIRP
(depending on transducer)
Broadband
50 kHz
83 kHz
200 kHz
(depending on Broadband transducer)
Active Imaging
800 kHz
455 kHz
Active Imaging HD (Via additional S3100 module)
DownScan:
700 kHz CHIRP
1200 kHz CHIRP
SideScan:
455 kHz CHIRP
1075 kHz CHIRP
|
| Multifunction Support |
AIS
AIS chart overlay.
Target vessel details.
Autopilot
Outboard Pilot
Ghost® Trolling Motor
Recon™ Trolling Motor
MotorGuide Xi5/Xi3 Trolling Motor (requires Motorguide PinPoint Gateway)
Cartography included
AUS/NZ Enhanced Basemap
Cartography supported
C-MAP® REVEAL™
C-MAP® DISCOVER™
C-MAP® Genesis
Navionics (Gold, NAV+ Platinum+)
Lowrance Regional Mapping Partners
GPS
10 Hz Internal high-sensitivity WAAS + EGNOS + MSAS
|
Multimedia
SonicHub
SonicHub2
FusionLink products
Any NMEA 2000 compliant marine audio products
Weather
SiriusXM via WM-4 (USA only)
Compass safe distance
12" (300mm)
Waypoints, routes, tracks
3000 Waypoints
100 Routes
100 Trails with up to 10,000 points per trail
|
| Environmental |
Operating temperature range
-15°C to 55°C (5°F to 131°F)
Storage temperature
-20°C to 60°C (4°F to 140°F)
Waterproof rating
IPX7 with card door closed
|
Humidity
60°C, 95% relative humidity (RH) for 18 hours
Shock and vibration
100,000 cycles of 20 G
|
